Custom TTX22M.2 205×65 MTBM 2248 Shock

The TTX22m.2 builds on the supreme levels of big hit performance, traction, and control that have made the original the go-to shock for gravity riders. The updated shock benefits from improved bottom out performance thanks to a newly designed bump rubber, as well as the cup it sits in. This significantly improves mid to end stroke control as a result of earlier engagement and more consistent, predictable support. The new design also minimizes the risk of a hard bottom out that may affect handling.
Changing the spring and stroke is easy on the TTX22 m.2 – no special tools or shock disassembly are required. The shock’s blue trail high-speed compression valve also provides a wider adjustment range. This gives riders more distinct alternatives to choose from when customizing setup, with added support in the pedal mode to make the bike a more efficient climber. The golden DH compression valve retains the same adjustment range as the original, which is already perfectly optimized for gravity riding. We have also developed two new cylinder heads for the TTX22m.2, making the shock more adaptable.

Specifications:

– TTX technology
– Specifically designed for trail and downhill use
– 250/225 length with golden DH compression valve; blue trail valve for all other lengths
– Available in metric lengths/strokes
– Trunnion piggyback cylinder head
– 205×65/62.5/60/57.5mm
– Possible to simply adjust stroke with the three 2.5 mm spacers included in the box
– Suitable for our lightweight springs with 4 Nm/23 lbs increments
– External, three level high-speed compression adjustment
– External, 16 click low-speed compression adjustment rebound damping adjustment
– External, seven click rebound adjustment
– Weight: 486g (for Trunnion shock 205×65)
